2 Pole MCB – 6 kA C Curve 32A DIN Rail Miniature Circuit Breaker

Introduction

This 2 pole MCB is a high-performance miniature circuit breaker designed to provide reliable overcurrent and short-circuit protection for single-phase electrical systems. Featuring a 32A current rating, 6 kA breaking capacity, and C curve tripping characteristic, this dual-pole breaker is CE certified, constructed with durable PA66 material, and engineered for simple DIN rail mounting—making it ideal for residential, commercial, and solar energy applications.

Key Features

• ✅ Rated Current: 32A

• ✅ Poles: 2 Pole (Dual Pole MCB)

• ✅ Breaking Capacity: 6 kA

• ✅ Tripping Characteristic: C Curve

• ✅ Rated Voltage: 240/415V AC

• ✅ Material: Flame-retardant PA66 housing for enhanced safety and durability

• ✅ Mounting: Easy DIN rail installation (35mm standard)

• ✅ Certifications: CE & CB certified, compliant with IEC/EN 60898-1 and IEC/EN 60947-2

• ✅ Electrical & Mechanical Life: 4,000 electrical operations / 10,000 mechanical operations

• ✅ Protection Rating: IP20

• ✅ Applications: Suitable for single-phase circuits, commercial panels, solar PV systems, and lighting control

Applications

• Residential single-phase distribution boards

• Commercial and office electrical systems

• Solar energy installations and inverter protection

• Motor control and appliance circuits

• Lighting and socket circuits in households and shops

Technical Specifications

• Type: Miniature Circuit Breaker (MCB)

• Rated Frequency: 50/60 Hz

• Mounting Type: DIN Rail

• Color: White

• Warranty: 3 Years

• Standard Compliance: IEC/EN 60898-1, IEC/EN 60947-2

Why Choose This 2 Pole MCB?

This 2 pole MCB offers complete circuit isolation for live and neutral wires, ensuring enhanced safety in single-phase systems. Its C curve tripping characteristic provides optimal protection against overloads and short circuits, while the 6 kA breaking capacity ensures reliable performance under fault conditions. The PA66 housing delivers excellent thermal and mechanical resistance, and the DIN rail design allows for quick and secure installation. Whether used in home electrical panels, commercial distribution boards, or renewable energy systems, this MCB is built for durability, safety, and compliance with international standards.
