Waterproof 60W Power Solution for Outdoor Applications
The LPV-60W 60W waterproof irrigation switch power supply provides reliable performance in demanding outdoor environments, utilizing components that meet industrial durability standards. This rugged power unit offers exceptional protection against moisture and dust, making it a trusted choice for agricultural and irrigation applications.
Advanced Technical Specifications
Featuring robust power conversion technology, this waterproof PSU delivers:
-
Dual output options: 12V/5A or 24V/2.5A
-
Wide input range: AC 90-264V (47-63Hz)
-
High efficiency: Up to 83%
-
Low ripple noise: <150mV
-
Precise regulation: ±1% line, ±2% load regulation
Superior Waterproof Protection
Moreover, this power supply features:
-
IP67 rated enclosure for complete weather protection
-
Corrosion-resistant housing
-
Sealed connectors against moisture ingress
-
UV-resistant materials for outdoor use
Comprehensive Safety Systems
Additionally, multiple protection mechanisms ensure reliability:
-
Overload protection with auto-recovery
-
Over-voltage protection circuitry
-
Leakage current protection <2.5mA
-
3KVAC isolation for enhanced safety
Agricultural Irrigation Applications
Specifically designed for farming applications:
-
Irrigation control systems
-
Agricultural automation equipment
-
Greenhouse control systems
-
Livestock watering systems
Outdoor Industrial Uses
Furthermore, ideal for harsh environments:
-
Outdoor lighting systems
-
Security and surveillance equipment
-
Park and garden automation
-
Remote monitoring stations
Environmental Durability
Notably, the construction withstands:
-
Wide temperature range: -30℃ to +70℃
-
High humidity: 20-90% RH
-
Extreme weather conditions
-
Direct sunlight exposure
Easy Installation Features
Importantly, the design includes:
-
Compact dimensions: 168×48×33mm
-
Lightweight construction: 900g
-
Multiple mounting options
-
Weatherproof cable entries
Quality Certifications
Finally, the product maintains:
-
IP67 waterproof certification
-
CE safety compliance
-
RoHS environmental standards
-
Industrial-grade component quality
Long-tail Keywords Coverage
Technical Specification Keywords
-
“60W waterproof power supply IP67 rated”
-
“12V 24V outdoor power supply agricultural”
-
“wide voltage input 90-264VAC waterproof PSU”
Application Specific Keywords
-
“irrigation system power supply waterproof”
-
“agricultural automation power supply 60W”
-
“outdoor lighting power supply IP67”
Environmental Protection Keywords
-
“weatherproof power supply for outdoor use”
-
“dustproof and waterproof power supply”
-
“outdoor industrial power supply 60W”
Quality Assurance Keywords
-
“reliable alternative to Meanwell waterproof PSU”
-
“industrial grade waterproof power supply”
-
“high reliability outdoor power unit”
| LPV-60 60W Waterproof Irrigation Switch Power Supply | |||||
| Project | Technical index | ||||
| Output | DC voltage | 12V | 24V | ||
| Rated current | 5A | 2.5A | |||
| Rated power | 60W | 60W | |||
| Ripple and noise ① | ＜120mV | ＜150mV | |||
| Voltage Precision | ±5% | ||||
| Load adjustment rate | ±2% | ||||
| Linear adjustment rate | ±1% | ||||
| Starting and rising time | 500ms、20ms、16ms ：115VAC 500ms、20ms、50ms ：230VAC | ||||
| Input | Voltage range/ frequency | 90-264VAC 47Hz～63Hz；127VDC～370VDC | |||
| Efficiency (typical)② | ＞81% | ＞83% | |||
| Working current | 1.5A/110VAC 1.1A/230VAC | ||||
| Impulse current | 220VAC： 60A | ||||
| Protect | Leakage current | 105%-135% Protection type: burping mode, automatic return to normal after removing abnormal conditions | |||
| overload protection | 115% – 145% protection type: close the output, restart and automatically return to normal | ||||
| Environmental Science | Working temperature and humidity | -30℃～+70℃；20%～90RH | |||
| Storage temperature and humidity | -40℃～+85℃；10%～95RH | ||||
| Safety regulations | Withstand voltage | Input output:3KVAC 1 minute | |||
| Leakage current | input shell: 240VAC时 ＜2.5mA | ||||
| Isolation Resistance | Input output, input shell, output shell ：500VDC/100MΩ | ||||
| Other | size | 168*48*33mm | |||
| Net weight / gross weight | 900/1200g | ||||
