High-Capacity Waterproof Solution for Demanding Outdoor Applications
The LPV-200W 200W waterproof irrigation switch power supply delivers robust performance for large-scale outdoor installations, engineered with components meeting industrial durability standards. This high-power unit provides reliable operation for agricultural and industrial applications, making it a premium choice for heavy-duty outdoor installations.
Advanced Technical Specifications
Featuring high-capacity power conversion technology, this waterproof PSU delivers:
Dual output options: 12V/16.6A or 24V/8.3A
Wide input range: AC 90-264V (47-63Hz)
High efficiency: Up to 88%
Low ripple noise: <200mV
Precise regulation: ±1% line, ±2% load regulation
Robust construction: 218×68×42mm compact design
Superior Weatherproof Construction
Moreover, this industrial-grade power supply features complete environmental protection:
IP67 rated enclosure for extreme weather conditions
Heavy-duty corrosion-resistant housing
Fully sealed waterproof connectors
Industrial-grade UV-resistant materials
Comprehensive Protection Systems
Additionally, advanced multi-layer safety mechanisms ensure maximum reliability:
Intelligent overload protection with automatic recovery
Multi-stage over-voltage protection
Advanced leakage current protection <2.5mA
3KVAC reinforced isolation for maximum safety
Surge and spike protection for unstable grids
Large-Scale Agricultural Applications
Specifically engineered for modern agricultural operations:
Commercial irrigation control systems
Large greenhouse automation networks
Farm sensor and monitoring systems
Agricultural processing equipment power
Industrial Outdoor Applications
Furthermore, perfectly suited for demanding industrial environments:
Outdoor industrial LED lighting systems
Perimeter security and surveillance networks
Remote telecommunication equipment
Industrial automation in harsh environments
Enhanced Environmental Durability
Notably, the rugged construction withstands extreme operating conditions:
Extended temperature range: -30℃ to +70℃
High humidity operation: 20-90% RH non-condensing
Superior weather and dust resistance
Long-term outdoor reliability
Professional Installation Features
Importantly, the design supports easy professional deployment:
Optimized dimensions: 218×68×42mm
Industrial-weight construction: 1100g
Multiple heavy-duty mounting options
Professional cable management system
Quality and Compliance Assurance
Finally, the product maintains the highest industry standards:
IP67 waterproof certification
International safety compliance
RoHS environmental standards
Industrial-grade component quality
| LPV-200 200W Waterproof Switch Power Supply | |||||
| Project | Technical index | ||||
| Output | DC voltage | 12V | 24V | ||
| Rated current | 16.6A | 8.3A | |||
| Rated power | 199.2W | 199.2W | |||
| Ripple and noise ① | ＜120mV | ＜200mV | |||
| Voltage Precision | ±5% | ||||
| Load adjustment rate | ±2% | ||||
| Linear adjustment rate | ±1% | ||||
| Starting and rising time | 2000ms、25ms、15ms ：115VAC 2000ms、25ms、50ms ：230VAC | ||||
| Input | Voltage range/ frequency | 90-264VAC 47Hz～63Hz；127VDC～370VDC | |||
| Efficiency (typical)② | ＞87% | ＞88% | |||
| Working current | 3A/110VAC 1.7A/230VAC | ||||
| Impulse current | 220VAC： 60A | ||||
| Protect | Leakage current | 105%-135% Protection type: burping mode, automatic return to normal after removing abnormal conditions | |||
| overload protection | 115% – 145% protection type: close the output, restart and automatically return to normal | ||||
| Environmental Science | Working temperature and humidity | -30℃～+70℃；20%～90RH | |||
| Storage temperature and humidity | -40℃～+85℃；10%～95RH | ||||
| Safety regulations | Withstand voltage | Input output:3KVAC 1 minute | |||
| Leakage current | input shell: 240VAC时 ＜2.5mA | ||||
| Isolation Resistance | Input output, input shell, output shell ：500VDC/100MΩ | ||||
| Other | size | 218*68*42mm | |||
| Net weight / gross weight | 1100/1200g | ||||
