High-Power Waterproof Solution for Demanding Outdoor Applications
The LPV-100W 100W waterproof irrigation switch power supply provides robust performance in challenging outdoor environments, engineered with components meeting industrial durability standards. This high-capacity power unit delivers reliable operation for agricultural and industrial applications, making it a preferred choice for demanding outdoor installations.
Advanced Technical Specifications
Featuring enhanced power conversion technology, this waterproof PSU delivers:
-
Dual output options: 12V/8.5A or 24V/4.2A
-
Wide input range: AC 90-264V (47-63Hz)
-
High efficiency: Up to 88%
-
Low ripple noise: <150mV
-
Precise regulation: ±1% line, ±2% load regulation
-
Fast startup: 2000ms maximum startup time
Superior Weatherproof Construction
Moreover, this power supply features complete environmental protection:
-
IP67 rated enclosure for total weather resistance
-
Corrosion-resistant metal housing
-
Sealed waterproof connectors
-
UV-stabilized materials for extended outdoor life
Comprehensive Protection Systems
Additionally, advanced safety mechanisms ensure reliability:
-
Overload protection with automatic recovery
-
Over-voltage protection with restart capability
-
Leakage current protection <2.5mA
-
3KVAC isolation for maximum safety
-
Surge and spike protection
Agricultural Automation Applications
Specifically designed for modern farming:
-
Large-scale irrigation control systems
-
Agricultural sensor networks
-
Greenhouse automation systems
-
Livestock management equipment
Outdoor Industrial Applications
Furthermore, ideal for industrial outdoor use:
-
Outdoor LED lighting systems
-
Security and surveillance networks
-
Park and landscape automation
-
Remote telemetry systems
Enhanced Environmental Durability
Notably, the construction withstands extreme conditions:
-
Wide temperature range: -30℃ to +70℃
-
High humidity operation: 20-90% RH
-
Resistance to weather extremes
-
Dust and moisture protection
Optimized Installation Features
Importantly, the design facilitates easy deployment:
-
Compact dimensions: 163×68×42mm
-
Lightweight construction: 900g
-
Multiple mounting options
-
Weatherproof cable management
Quality and Compliance
Finally, the product maintains highest standards:
-
IP67 waterproof certification
-
CE safety compliance
-
RoHS environmental standards
-
Industrial-grade component quality
| LPV-100 100W Waterproof Switch Power Supply | |||||
| Project | Technical index | ||||
| Output | DC voltage | 12V | 24V | ||
| Rated current | 8.5A | 4.2A | |||
| Rated power | 102W | 100.8W | |||
| Ripple and noise ① | ＜120mV | ＜150mV | |||
| Voltage Precision | ±5% | ||||
| Load adjustment rate | ±2% | ||||
| Linear adjustment rate | ±1% | ||||
| Starting and rising time | 2000ms、25ms、15ms ：115VAC 2000ms、25ms、50ms ：230VAC | ||||
| Input | Voltage range/ frequency | 90-264VAC 47Hz～63Hz；127VDC～370VDC | |||
| Efficiency (typical)② | ＞85% | ＞88% | |||
| Working current | 2.2A/110VAC 1.2A/230VAC | ||||
| Impulse current | 220VAC： 60A | ||||
| Protect | Leakage current | 105%-135% Protection type: burping mode, automatic return to normal after removing abnormal conditions | |||
| overload protection | 115% – 145% protection type: close the output, restart and automatically return to normal | ||||
| Environmental Science | Working temperature and humidity | -30℃～+70℃；20%～90RH | |||
| Storage temperature and humidity | -40℃～+85℃；10%～95RH | ||||
| Safety regulations | Withstand voltage | Input output:3KVAC 1 minute | |||
| Leakage current | input shell: 240VAC时 ＜2.5mA | ||||
| Isolation Resistance | Input output, input shell, output shell ：500VDC/100MΩ | ||||
| Other | size | 163*68*42mm | |||
| Net weight / gross weight | 900/1200g | ||||
